Novo Gloss Trigloss Gloss Meter 20/60/85˚
20/60/85° Gloss meter for matt to mirror finishes
Now features haze measurement to ASTM E430
Full statistical analysis with trend graphs
The Novo-Gloss 20/60/85° gloss meter is designed to meet the measurement criteria for most gloss measuring applications.
Small, lightweight and durable the gloss meter can be used in production and laboratory environments. The high specifications, including statistical analysis, graphical analysis and software-free PC down load facility make it the ideal gloss meter for matt to mirror surface finishes
Measured parameters:
Gloss measurement for all surface finishes:
- 20⁰ – High gloss
- 60⁰ – Medium gloss
- 85⁰ – Low gloss
Haze measurement to ASTM E430
- Reflectance haze measurement with compensation mode to provide consistent readings of metallics and speciality pigments
Gloss meter features
- Fast measurement, single button push measures all parameters
- On-board statistics with graphical trend analysis and reporting.
- Automatic calibration with tile validation
- Date and time stamped results
- Easy Batching – User definable batch names and batch sizes for quicker and more efficient reporting
- Software-free data transfer
- Direct data input via Bluetooth – instantly transmit measured readings directly to programs such as Microsoft Excel
- Auto-ranging, measures matt to mirror finishes
- Pass / fail for easy identification of non-conformances
- Compatible with all major international standards
- Extended two year warranty
- Lifetime lightsource guarantee
Gloss meter specifications
GLOSS
60°, 20/60°* and 20/60/85°* versions availiable
| 20° | Improved accuracy and resolution on high gloss & metallic samples (>70GU when measured at 60°) | |
| 60° | Universal angle – all gloss levels | |
| 85° | Improved resolution for matt finishes ( |
Resolution 0.1GU • Repeatability ±0.2GU • Reproducibility ±0.5GU
Resolution 0.1GU • Repeatability ±0.2% • Reproducibility ±0.5%
Measurement range:
20º: 0-2000GU
60º: 0-1000GU
85º: 0-199GU
Standards:
ISO 2813, ISO 7668
ASTM D523, ASTM D2457
DIN 67530
JIS 8741, JIS K 5600-4-7
*Verified performance on 20° angle for 20/60/85°
INSTRUMENT SPECIFICATIONS
Operation
- Full colour easy to read screen
- Adjustable brightness6 button touch sensitive interface
Construction
- Integrated calibration holder with in-position detector for
error free calibration
Measurement
- Single button push to measure all parameters
- Fast measurement
- Results batching with user definable names
Statistical Analysis
- Max, min, mean, S.D.
Graphical Analysis
- On board trend analysis
- Gloss values
Power
- Rechargeable lithium ion
- 17+ hours operation
- 10,000+ readings per charge
Memory
- 8MB= >2000 readings
- User defineable alphanumeric batching
Data Transfer
- Bluetooth
- PC compatible
- USB connection, no software install required
Measurement Area
- 20°: 6mm x 6.4mm
- 60°: 6mm x 12mm
- 85°: 4.4mm x 44mm
- Operating Temperature: 15 – 40 ° C (60 – 104 ° F)
- Humidity: Up to 85%, non condensing
Dimensions & Weight
- 65mm x 140mm x 50mm (H x W x D)
- 60º & 20/60º = 390g, 20/60/85º = 530g
- Packed weight: 1.6kg
- Packed dimensions: 110mm x 280mm x 220mm (H x W x D)
- Commodity code: 9027 5000
